Antenna 860-960 MHz GSM 3G Dipole OmniDirectional 5dBi w/ SMA or RP-SMA
- SKU:
- A9D5SRA
- Availability:
- In stock
- Weight:
- 0.19 LBS
Data Alliance
900 MHz Dipole Omni Directional w/ SMA or RP-SMA
Compatibility with wireless standards & applications: This omni directional antenna's range of frequency band compatibility in the 860 MHz to 960 MHz frequency band range, its low broadband VSWR, and impedance matching to 50 Ohm gear, makes it suitable and compliant for all the following applications:
- Compatible with Wi-Fi HaLow devices, as are all antennas in our Wi-Fi HaLow Antenas subcategory and LoRaWAN access points.
- Non Line of Sight (NLOS): 900 MHz band is best for passing through trees and forests.
- 900MHz ISM Band. Can also be made to operate on other VHF and UHF frequencies within the ISM frequency bands .
- IoT wireless & M2M: Bluetooth, ZigBee, Wi-Fi HaLow and ISM. Since it is vertically polarized, it is compatible with many machine to machine communication applications, remote monitoring, and telemetry applications.
GSM Antenna (Global System for Mobile Communication): Omni-Directional dipole antenna for the 860-960MHz band.
- This band is used for GSM (Global System for Mobile Communication): 860-960MHz cellular phone band.
- Connector options: SMA & RP-SMA
- Articulating right-angle means that the right-angle is bendable and can be in a straight position, or right-angle position. The straight version stands up to weather longer than the right-angle antenna.
| SPECIFICATIONS: | |
| Frequency | 860-960 MHz: 4G networks: AT&T Mobility & Verizon |
| Antenna Connector | SMA & RP-SMA options |
| Gain (dBi) | 5 dBi |
| Antenna Type | Dipole omni-directional |
| Polarization |
Linear Vertical |
| VSWR | <=1.8 |
| Max Power | 50W |
| Impedance | 50 |
| Antenna Color | Black |
| Weight | 53g (2oz) |
| Dimension | L390xW13.7XH13.7mm (15.4 x .54 x .54 in) |
TEST RESULTS for FREQUENCY RANGES:
The antenna exhibits very favorable performance in the approximate frequency range of 878 to 933 MHz, with optimal impedance matching around 878 MHz. S11 measurements show a minimum VSWR of about 1.21 and a Return Loss of approximately −20.3 dB, indicating excellent power transfer and very low reflection losses at that point.
| Frequency range | Assessment | Rating | Compatible technologies |
|---|---|---|---|
| 0.88–0.93 GHz | Excellent | ★★★★★ | Cellular 900 MHz bands (GSM/EDGE 900), LTE Band 8, NB-IoT / LTE-M deployments in the 900 MHz range, UHF RFID systems (regional 860–960 MHz), sub-GHz telemetry links, smart metering infrastructure, and long-range IoT communication systems. Excellent impedance matching around 878 MHz, with a minimum VSWR of approximately 1.21 and Return Loss near −20.3 dB, ensuring very efficient power transfer and minimal reflection losses across the band |
Connector, cable and Antenna are all compliant with ROHS 3 & REACH.
RP-SMA and SMA Connector Characteristics:
COMPATIBLE MOUNTS & TECH SUPPORT PAGES
- L-Mount / bracket for Dipole Antennas with SMA or RP-SMA connector.
- Magnetic bases that fit this antenna and have antenna cables with various connector-types.
- Antennas: How to choose
- Directional Antennas
- Omni-Directional Antennas
- Wireless Frequencies: 2.4GHz, 5GHz, 900MHz, WiMAX
All of our antennas pass QC test before we ship them.
